Charactristic

• Compatible with 1080P@60Hz/4K@30Hz

• Support LPCM 7.1CH, Dolby True HD, Dolby digital + and DTS-HD Master Audio output

• Support any signal source displayed simultaneously on multiple displays

• Support any HDMI signal sources to be viewed on any HDMI displays at any time

• Support crystal button with green background light

• Two-key control method enabling easier and more effective controlling, support 1 port input and multiple ports output when switching images

• Support channel fast closure

• Indicator lights of visual buttons enabling the input and output channel operation status to be visible

• Supports EDID learning and EDID adaptive function enabling it to meet the needs of field diversification display devices, and also improved compatibility

• Support RS-232, LAN, front-panel and IR control

• Spiral power connectors guaranteed stable power supplying

Technology

1. Name

   HDMI immobilization matrix

2. Input

   8×HDMI

3. Output

   16×HDMI

4. Resolution

   480i, 576i, 480p, 576p, 720p ,1080i, 1080p@24/30/50/60Hz, 4K@30Hz

5. Control

   Dual RS232(In/ out), LAN, front buttons, IR

6. Power Supply

   AC:110V-240V 50/60Hz, DC12V/3A

7. Protocol

   Support HDMI, HDCP compatible, EDID Learning

Routine

1. Consumption

   36W

2. Dimensions(mm)

   482×282×89

3. Weight

   3.9 Kg

4. Working Humidity

   10%-90%

5. Working Temperature

   -10℃ - 50℃

6. Storage Temperature

   -25℃ - 55℃
