Charactristic

• Can be configured as transmitter (encoder) and receiver (decoder)

• 4K UHD through 1g switch network cable or optical fiber

• Video lossless coding 1.5 frame delay

• 1G network port supports Poe power supply

• 1DP input, 1hdmi input, 1hdmi output

• Analog audio input and output, support audio de embedding, audio synchronization in video or independent switching applications

• RS232 control input and output, support the central control or PC to send control commands to RS232 through the network

• IR input and output, support sending IR control code to IR transmitter through network, and support IR receiving and learning Control code network output

• KVM application, support OSD agent switching function and authority management

• Built in Web terminal setting and PC software configuration control

Technical

1. Delay

   1.5 frames（25ms）

2. 1G Copper Ethernet

   RJ-45,100m transmission distance

3. 1G Fiber Ethemet

   LC single mode,10 km transmission distance

4. LAN RJ-45

   10/100/1000M POE(PD)

5. Video bandwidth

   340MHz

6. Resolution support

   4K2K 4:4:4@30Hz

7. RS -232

   Support 115K baud rate (Phoenix terminal)

8. IR

   Bidirectional (3.5mm TRS)

9. USB connector

   2 USB 2.0 type A and 2 USB 1.1 type A

Interface

1. DP input 1

   (DP1.2)

2. HDMI input 2

   (HDMI 1.4,HDCP 1.4)

3. HDMI output

   (HDMI 1.4,HDCP1.4)

4. Control interface

   KET,RS-232.IR,OSD,WEB TELNET and PC Software

Audio

1. Audio mode

   Analog audio line In /out(3.5mm TRS)

2. Audio switching

   Support audio and video synchronous switching

Strcture

1. Chassis

   Industrial ash cabinet

2. Dimensions [l x W x H]

   232 x 135 x 32mm

3. Weight

   700g

4. Install

   Rack mounting lug and table bottom mounting lug

5. Power Supply

   12V DC with lock and POE (LAN)

6. Power waste

   8 Watts

7. Working temperature

   0~40°C [32~104℉]

8. Packing

   1 x host and 1 x PSU(DC 12V 2a)
